JP-DIP800-B 6063-T5 Aluminum Bilateral Automatic PCB Plug-in Line 3m 4m 6m Customizable Dual-Side DIP Conveyor

The JP-DIP800-B Bilateral Automatic PCB Plug-in Line is a dual-side through-hole assembly conveyor purpose-built for the DIP plug-in (manual insertion) stage of modern electronics manufacturing. Mounted on a high-strength 6063-T5 industrial aluminum profile frame with an anodized finish, it pairs a lightweight, corrosion-resistant structure with the rigidity needed for continuous production. Standard line lengths of 3m, 4m and 6m can be freely selected, and non-standard dimensions are fully customizable so the conveyor matches your workshop footprint instead of forcing your layout to match the machine.

Operators work comfortably from both sides of the anti-static belt, allowing two rows of plug-in stations to run in parallel. The result is higher output per square meter of floor space, shorter walking distance, and a cleaner DIP assembly flow that connects smoothly with your existing SMT line, wave soldering machine and PCB loader or unloader.

• 6063-T5 Aluminum Profile Frame: Anodized aluminium alloy construction resists corrosion and chemical wear while staying light enough for quick relocation and re-layout. Adjustable foot cups keep the line level even on uneven factory floors.
• Bilateral Dual-Side Working Design: Two rows of operators insert resistors, capacitors, connectors and other through-hole parts simultaneously, sharply boosting throughput compared with two separate single-side lines.
• Customizable 3m / 4m / 6m Lengths: Choose the standard length that fits your space, or request a fully non-standard size. Height, PCB width range, lighting, sockets and baffles can all be tailored.
• Full ESD Anti-Static Protection: An imported anti-static green PVC belt with surface resistance of 10⁶ to 10⁹ ohm, green anti-static work panels and an ESD grounding port at every station protect sensitive components from static damage.
• Stepless Variable-Speed Conveying: A 220V single-phase variable-speed motor delivers smooth regulation from 0.1 to 5 m/min, letting supervisors match the line speed to each production beat without step changes.
• Seamless DIP Line Integration: The conveyor docks directly with wave soldering machines, SMT equipment and PCB handling machines to form a complete automatic DIP assembly workflow.
• Tool-Free Modular Maintenance: A modular aluminium structure simplifies daily inspection, parts replacement and future production re-arrangement, keeping downtime low.

The JP-DIP800-B serves workshops assembling household appliance circuit boards, switching power supplies, LED driver boards, automotive electronic control boards, industrial controller PCBs, medical electronic circuit boards and security equipment motherboards. Wherever DIP through-hole components must be inserted at volume with consistent quality, this aluminium dual-side conveyor keeps operators productive and boards protected from static discharge.

Each line is packed in a reinforced plywood case with foam protection and shipped with an assembly drawing and operation manual; parts are arranged by module to simplify installation. Shenzhen Jingji Technology Co., Ltd. manufactures under an ISO9001 quality management system and provides on-site installation guidance, operator training and lifelong technical support. Engineering layout drawings and 3D simulation are available before production so that your 3m, 4m or 6m configuration is confirmed in advance.
